Rapid Heatup, recovery and cooldown

° Featureheating elements with unique right-angle bend and sidewallmountingto deliver exceptional energy release, reduced thermal processcycletime, and cost savings through quicker throughput and energyefficiency

° Moldathermgraduated-density insulation provides safety, performanceandoutstanding radial and linear temperature uniformity with resistance tothermal shock​

° Heatingelements tolerate rapid cycling over extended periods; elements areeasily replaceable without the need to match resistance values​

° Type “B”thermocouples assure accurate temperature measurement and longthermocouple life; 10ft. compensated lead wire with polarized plug included​

° Moldathermgraduated density insulation adds to safety and performanceby forming enhanced insulation protection between the high-temperaturechamber and exterior cabinet surface

​

° Doubleshell construction and convection cooling design reduces exteriorsurface temperature

​

° Removablelouvered panels provide easier access to heating elements and thermocouple

° Temperature range: 500°C to 1700°C
