PRODUCT

  • Digital Dry Baths Heaters

    Increase lab versatility with the Thermo Scientific™ digital dry baths, which offer a range of configurations with interchangeable modular blocks for a variety of application needs. Designed for basic to advanced applications with a max temperature of 130°C, a timer and available in 1, 2 and 4 block sizes.

    제조사

    Thermo Scientific U.S.A.

    제품명

    Digital Dry Baths Heaters

    사이즈

    288 x 200 x 100 mm (11.3 x 7.9 x 3.9 in.)

    상대습도

    <80%

    온도범위(미터법)

    Ambient +5°C to 130°C (Ambient at 25°C)

    가열속도

    ≤ 20 min. 30° to 130°C

    온도정확도

    ≤ ± 0.5°C

    온도균일성

    ≤ ± 1°C

    타이머기능

    0 to 99:59 min or continuous

제품사양

Thermo Scientific digital dry baths are available in a range of configurations to hold 1, 2 and 4 interchangeable modular blocks to accommodate a variety of vessels and applications.
  • -Digital controls and display of time and temperature
  • -Advanced internal temperature sensing probe for outstanding temperature accuracy and control
  • -Precise temperature control with PID circuit
  • -Temperature calibration allows the user to offset the temperature to desired value
  • -Timer allows the user to accurately monitor the heating time
  • -Wide range of interchangeable aluminum alloy heat blocks provide versatility and allow for easy cleaning and disinfecting
  • -Powder-coated steel body construction ensures durability
  • -Built-in over-temperature protection device ensures sample and user safety
  • -Temperature deviation adjustment
Applications:
  • -Sample preparation
  • -Enzyme preservation
  • -Enzyme-substrate reactions
  • -DNA amplification
  • -Electrophoresis gel degeneration
  • -Serum coagulation
Required Accessory:
  • -Unit must be ordered with block(s)
    Thermo Scientific digital dry baths are available in a range of configurations to hold 1, 2 and 4 interchangeable modular blocks to accommodate a variety of vessels and applications.
    • -Digital controls and display of time and temperature
    • -Advanced internal temperature sensing probe for outstanding temperature accuracy and control
    • -Precise temperature control with PID circuit
    • -Temperature calibration allows the user to offset the temperature to desired value
    • -Timer allows the user to accurately monitor the heating time
    • -Wide range of interchangeable aluminum alloy heat blocks provide versatility and allow for easy cleaning and disinfecting
    • -Powder-coated steel body construction ensures durability
    • -Built-in over-temperature protection device ensures sample and user safety
    • -Temperature deviation adjustment
    Applications:
    • -Sample preparation
    • -Enzyme preservation
    • -Enzyme-substrate reactions
    • -DNA amplification
    • -Electrophoresis gel degeneration
    • -Serum coagulation
    Required Accessory:
    • -Unit must be ordered with block(s)
    Thermo Scientific Digital Dry Baths / Block Heaters Ordering Information and Specifications

  •  Cat No.

     88870004

     88870005

     88870006

     Voltage/Hz

     200-240V 50/60Hz

     Block Capacity

     1

     2

     4

     Controller Type

     PID digital

     Temperature Range

     + 5°C – 130°C (Ambient at 25°C)

     Temperature Control Accuracy at 37°C

      ≤ ± 0.5°C

     Temperature Uniformity at 37°C

     ≤ ± 1°C





     Timer Range

     0-99:59 min or continuous

     Heating Up Time

     ≤ 20 min 30°C to 130°C

     ≤ 25 min 30°C to 130°C

     Relative Humidity Tolerance

     ≤ 80%

     Dimensions L x W x H

     288 × 200 × 100 mm 11.3 x 7.9 x 3.9 in

     318 × 200 × 100 mm 12.5 x 7.9 x 3.9 in

     450 × 200 × 100 mm 17.7 x 7.9 x 3.9 in

     Weight

     2.9 kg 6.39 lbs.

     3.3 kg 7.28 lbs.

      4.7 kg 10.36 lbs.

     Required Accessories

    1 block

     2 blocks

     3 blocks

     Certification

     CE cULus RoHS

  • UNIT MUST BE ORDERED WITH A BLOCK
